What is Computed Radiography?
How does it work?
DÜRR NDT Imaging Plates
The phosphor imaging plates (IPs) are specifically designed to fit the needs of the nondestructive testing industry, available in different resolutions and formats, up to 35 cm (14") width and virtually unlimited length. IPs are fully flexible X-ray detectors and extremely versatile.
| Imaging Plates | UH | HD / XHD | HCR | CR / GCR |
| Max. SRb (basic spatial resolution) |
30 µm | 40 µm | 63 µm | 100 µm |
| Minimum radiation dose for max. SRb |
15.5 mGy (1.5 rd) |
6 / 12 mGy (0.6 /1.2 rd) |
3.3 mGy (0.33 rd) |
1.4 mGy (0.14 rd) |
Additional products
CR 35 imaging plate protectors
Reduces wear during the feeding process and prolongs the imaging plate lifetime.
Single-use protection sleeves
Protects imaging plates from physical damage and prolongs the imaging plate lifetime.
Flexible cassettes
For the secure handling and protection of the imaging plate during the exposure.
Rigid cassettes
For the secure handling and protection of the imaging plate during exposure.
IP-Cleaning Wipe
Special cleaning wipes with particularly good material compatibility, made specifically for use with the DÜRR NDT imaging plates.
Imaging Plate Scanners
HD-CR 35 NDT
High resolution Computed Radiography imaging plate scanner for all NDT radiography applications - weld testing, profile images and aerospace.
CR 35 NDT
Computed Radiography imaging plate scanner for for general purposes.
